Programmable Universal Converter with Bipolar output Z109REG-BP

Z109REG-BP is a converter with universal input in voltage (mV), current (mA), thermocouples (TC), thermoresistance (RTD), potentiometer, rheostat, NTC. The module allows the measurement and retransmission on bipolar isolated analogue output, in voltage or current. Exploiting the mini frontal USB port, Z109REG-BP can be programmed via PC with values of start and end-scale, kind of different input, root extraction, filter, burnout etc.

Talk to Our Experts Download Datasheet

Power Supply Vac/dc.
Power supply, 2-wire technique.
Selectable input V, mA, Ohm, thermocouple (TC), thermoresistance (RTD).
Selectable output mA (active/ passive), .
Alarm relay output (spst) / strobe input to enable analog output.
Sampling frequency from 240 sps (@11bit+sign resolution) to 15 sps (@15 bit+sign resolution).
Isolation 1.500 Vac at 3-ways power supply / input / output.
Setting via DIP switches, software or APP.
Micro USB connector (front side).

Sampling frequency from 240 sps (@11bit+sign resolution) to 15 sps (@15 bit+sign resolution).
Isolation 1.500 Vac at 3-ways power supply / input / output.
Setting via DIP switches, software or APP.
Micro USB connector (front side).

Power supply : 10-40 Vdc / 19-28 Vac / 50-60 Hz
Max consumption : 2 W
Power transducers : 2-wire active input (20 Vdc)
Input protection : Against Pulse Overvoltage 400 W/ms
Response time : From 35 ms (11 bit) and 140 ms (16 bit)
