Strain gauge converter Z-SG / Z-SG-L

Z-SG / Z-SG2 are strain gauge load cell converters. The measurement, carried out with 4 or 6-wire technique, is available via ModBUS RTU serial protocol or analog output. The communication is configurable via DIP-switch or via software by connecting to the device with the Micro USB port on the front panel.

Talk to Our Experts Download Datasheet

ADC with 24bit resolution
4 wires or 6 wires load cell measure mode
Compression and Traction or only compression load mode
NR 1 analog output configurable in Current or Voltage mode (only Z-SG model)
Load cell sensitivity configurable from +-1mV/V to +-64mV/V or virtually every sensitivity
Measure resolution configurable

RS232 and RS485 port with Modbus RTU protocol
Configurable Moving average filtering
Digital input for Tare acquisition (only Z-SG model)
General purpose Digital input or Digital output (only Z-SG-L model)
Digital output with one configurable weight threshold or “stable measure” condition
Modbus Station address and baud-rate configurable by Dip-Switches

Resolution : 24bits
Rejection : 50Hz or 60Hz
Supply voltage : 10 – 40 Vdc or 19 – 28 Vac ( 50Hz - 60Hz)
