Z-5DI2-DO 7-CH, 5 Digital Inputs, 2 Digital Outputs Module, RS485 – Modbus RTU

• NR 5 opto-insulation digital inputs with a common contact. Internal or external, NPN (sink) or PNP (source) selectable by software.
• Insulation of the 1500 Vac inputs complying with respect to the remaining low voltage circuits.
• NR 2 SPST relay outputs with common contact, capacity of 2 AAC1 250 Vac.

• 3 kVac insulation between the outputs and the remaining low voltage circuits.
• Inputs with 32 bit totalizers, max frequency 5 KHz.
• Measure of the period, frequency, TON, TOFF. Max frequency 5KHz.
• Possibility to set the totalizers for counting forward or backward
• All the totalizers are saved in a non-volatile memory (Fe-RAM).

Refer to the datasheet for more details.
