4-CH Thermocouple A/D converter Z-4TC-D
Z-4TC-D allows to acquire up to N.4 Thermocouple sensors (J,K, E, N, S, R ,B ,T) through a PLC with only digital input/output.
The PLC interface is based on three PNP-type signals suited for connection to most PLCs available in the market.
The interface is composed of a CLOCK signal generated by the PLC (transistor output), a DATA signal and STROBE signal generated by the module.
The interface is composed of a CLOCK signal generated by the PLC (transistor output), a DATA signal and STROBE signal generated by the module.
The PLC interface is based on three PNP-type signals suited for connection to most PLCs available in the market.
|
Power supply
|
: 10..40 Vdc, 19..28 Vac 50..60 Hz
|
|
Power consumption
|
: 2,5 W
|
|
Dimension
|
: (W x H x D) 17.5 x 100 x 112 mm
|
|
Mounting
|
: 35 mm DIN rail guide
|
|
Protection degree
|
: IP20
|
