AC/DC Voltage To 4-20 Ma Converter (Loop Powered) Z202-LP
Z202-LP is an universal converter for AC or DC voltages (0..500 Vac or 0..540 Vdc) and provides an isolated 4..20mA output. It’s a loop powered device through the 4..20mA loop output. Is possible to calibrate the instrument on any intermediate point in the continuous range of 0..500A. A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.
- Is possible to calibrate the instrument on any intermediate point in the continuous range of 0..500A.
- A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.Z202-LP is an universal converter for AC or DC voltages (0..500 Vac or 0..540 Vdc) and provides an isolated 4..20mA output.
- It’s a loop powered device through the 4..20mA loop output.
- A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.Z202-LP is an universal converter for AC or DC voltages (0..500 Vac or 0..540 Vdc) and provides an isolated 4..20mA output.
- It’s a loop powered device through the 4..20mA loop output.Is possible to calibrate the instrument on any intermediate point in the continuous range of 0..500A.
|
Power supply
|
: Powered through the 4..20mA loop output
|
|
Isolation
|
: 4000 Vac towards input / output ports.
|
|
Power transducers
|
: Yes
|
|
Accuracy
|
: 0,25%
|
|
Response time
|
: 100 ms
|
