DC current/voltage to frequency isolator/converter Z104
Z104 allows a conversion of the current or voltage input signal into a series of pulses with constant duration.A typical use is when, with a flow meter featuring an analogue output (example 4-20mA), the flow must be totalized. the output is programmable in a range from 1 pulse every 2 hours to 10 KHz. A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.
- A typical use is when, with a flow meter featuring an analogue output (example 4-20mA), the flow must be totalized.
- The output is programmable in a range from 1 pulse every 2 hours to 10 KHz. A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.
- Z104 allows a conversion of the current or voltage input signal into a series of pulses with constant duration.
- A typical use is when, with a flow meter featuring an analogue output (example 4-20mA), the flow must be totalized.
- The output is programmable in a range from 1 pulse every 2 hours to 10 KHz.
- A 3-way galvanic isolation among Power supply // input // output circuits assures the integrity of your datas.
|
Power supply
|
: 19..40 Vdc / 19..28 Vac / 50-60 Hz
|
|
Power consumption
|
: 2,5 W
|
|
Isolation
|
: 1.500 Vac (3 way)
|
|
Power transducers
|
: Yes
|
