DC Duplicator Z170REG-1
The Z170REG-1 module acquires a universal input signal and converts it into an analog format, returning two independent and isolated universal outputs.
Isolation voltage between power supply / input / output features 1.500 Vac.
The signal converter offers the possibility to choose between different types of input: voltage, current, potentiometer, thermocouple (TC) by thermoresistance (RTD).
The two analog outputs have 14-bit resolution. Selecting the current input it’s possible to power an external sensor. The module has a Micro USB connector on the front panel and can be configured by software or specific App for Android devices.
- Power Supply Vac/dc
- Power transducers
- Selectable input V, mA,
- Ohm, thermocouple (TC), thermoresistance (RTD)
- Dual selectable output mA (active/passive), V
- Sampling time from 5 to 20 ms
- Resolution @ 14 bit.
- Isolation1.500 Vac power supply / input / output
- Setting by DIP switches, software or APP
- Micro USB connector (front side)
- Operating temperature -10...+60°C
- UL Certification
|
Power supply
|
: 10..40 Vdc / 19..28 Vac
|
|
Max consumption
|
: 0.5..2 W
|
|
Power transducers
|
: Yes max 25 mA, 17 Vdc
|
|
Protection
|
: degree IP20
|
|
Isolation
|
: 1.500 Vac at 4 ways between input// power supply // output 1 // output 2
|
