Delta F nondepleting oxygen sensor
Delivering ultra-stable, trace oxygen analysis in industrial gas applications
The Delta F non-depleting, coulometric oxygen sensor provides ultra-stable oxygen measurement and requires only an annual span calibration. Combined with Panametrics’ moisture.IQ, this offers a cost effective six-channel solution for multipoint oxygen measurement covering ppm and ppb measurements. The Delta F sensor is particularly suited to applications requiring high sensitivity measurements for process control.
- Used with moisture series analyzers to measure oxygen concentration in gases from trace to percent levels
- Ultralow range for ultrapure gas applications is sensitive to less than 5 ppb oxygen
- Sensors available for indoor/outdoor water- and dust-tight enclosures
- No gas scrubbing equipment needed for acid gas applications
- No periodic replacement or reconditioning of cells is needed
- Intrinsically safe option available for hazardous areas
- Optional VCR fittings for enhanced system cleanliness and leak integrity
| Ambient temperature |
: 24 VDC ±2 VDC, 1.2 A maximum |
| Moisture |
: 316 stainless steel, glass and Viton® O-rings |
| Inlet pressure |
: 0.2 psig to 1.0 psig (0.013 barg to 0.06 barg) (standard range) |
| Flow rate |
: 0.5 to 1.5 SCFH |
