Double Alarm Threshold With Universal Input And Relay Output Z113-1
Z113-1 is an alarm threshold with two relay output SPST from 3A 250V with a common contact. The module allows to select the input type via DIP-switch: voltage, current, potentiometer, thermocouple (TC), thermoresistance (RTD). Input, output, input filter, rejection and burn-out can be configured through Software (via front USB port),
- Power Supply 10..40 Vdc, 19..28 Vac.
- Transducer power supply.
- Isolation 1.500 Vac between Power supply and input , 3.000 Vac in output.
- Nr 1 configurable input as mA, V, Ohm, RTD, TC.
- Nr 2 thresholds relay SPST, 3 A, 250 Vac.
- Configuration through software and Micro USB port (EASY SETUP).
- Z113-1 is an alarm threshold with two relay output SPST from 3A 250V with a common contact. The module allows to select the input type via DIP-switch: voltage, current, potentiometer, thermocouple (TC), thermoresistance (RTD).
- Input, output, input filter, rejection and burn-out can be configured through Software (via front USB port).
|
Power supply
|
: 10..40 Vdc; 19..28 Vac
|
|
Power consumption
|
: 2,5 W
|
|
Removable terminals
|
: Yes, current input (mx 17 V – 20 mA)
|
|
Isolation
|
: 1.500 V between input and Power supply (3.000 V output)
|
|
Protection degree
|
: IP20
|
