MOTOR MULTI-PROTECTION RELAY S91

S91 is a protection device for electric motors that allows the detection of wrong phase sequence or lack of a phase, of the excess current consumption, no-load operation with the power factor measurement. Equipped with rotary programming switches and a display of alarm signaling, the device is characterized by an input for PTC to protect the motor from overtemperature and enable input for starting the engine. S91 operates in 3 operation modes: single-phase or threephase, maximum current range 5 or 16 A, operation with or without PTC. Main applications are protection of single-phase or three-phase pumps for possible rotor stop and for overtemperature as well as device failure detection of mechanical transmission (e.g. belts or chains) with protection against transmission system lockdown.

Talk to Our Experts Download Datasheet

Front diagnostics via LED and display.
Simplified settings and adjustments via trimmer and front selector.
Current measurement up to 16 A directly or by Current Transformer.

Maximum rated voltage 660 Vac (F-F).
Motor control input 195 ÷ 255 Vac.
SPDT Relay @ 250 Vac – 8 A.
Alarm, temperature, power factor, maximum current, minimum voltage or phase failure management.
