On/Off Sensors Digital Amplifier, Single Channel Z112A
Z-Line Series offers a full range of signal conditioners including analog/digital/serial converters, temperature transmitters, galvanic isolators, splitters, trip amplifiers and math modules. They work at 10-40 Vdc/ 19-28 Vac, 85-265 Vac/dc or are supplied by the loop. Z-Line modules ensure from 1.500 Vrms to 4.000 Vrms isolation voltage for 1 minute at three points. They also supply the transducer and can have active/passive input/output and they are designed to be mounted on DIN 46277 rail.
- They work at 10-40 Vdc/ 19-28 Vac, 85-265 Vac/dc or are supplied by the loop.
- Z-Line modules ensure from 1.500 Vrms to 4.000 Vrms isolation voltage for 1 minute at three points.
- They also supply the transducer and can have active/passive input/output and they are designed to be mounted on DIN 46277 rail.
- Z-Line Series offers a full range of signal conditioners including analog/digital/serial converters, temperature transmitters, galvanic isolators, splitters, trip amplifiers and math modules.
- SENECA Z-Line offers three setting options.
- Almost all of the existing models allows configuration of standard parameters using the dip switches on board.
- In addition to the standard configuration some models can be configured for widen functionalities by using the PC software “EASY SETUP“ .
- Moreover, certain models are equipped with a frontal Micro Usb port for an easier configuration through “EASY SETUP APP“, a specific App for Android.
|
Power supply
|
: 19..40 (9..30 opt.) Vdc; 19..28 Vac; (50..60 Hz)
|
|
Power consumption
|
: 2.5 W
|
|
Power transducers
|
: Yes, active input 2 wire (min 20 Vdc)
|
|
Accuracy
|
: ±0,01% /°C
|
