Process Trace Oxygen Analyzer - 3010TA
Teledyne’s Model 3010TA Trace Oxygen Analyzer is a versatile microprocessor-based instrument for detecting oxygen at the parts-per-million (ppm) level in a variety of gases.
The 3010TA is designed as a “split architecture” instrument, meaning that a general purpose Control Unit for non-hazardous areas controls a specially designed Analysis Unit or “remote probe” that can operate in hazardous areas. Simple menu choices, membrane command switches and dual LCD and LED displays make set-up and operation clear and quick.
- An explosion proof NEMA 4/7 rated analysis unit enclosure
- A 2-line alphanumeric display screen, driven by microprocessor electronics continuously prompting and informing the operator
- High resolution, accurate readings of oxygen content from low ppm levels through 25%
- Stainless steel cell block
- Advanced Micro-fuel Cell designed for trace analysis
- Versatile analysis over a wide range of applications
- Microprocessor based electronics: 8-bit CMOS microprocessor with 32kB RAM and 128kB ROM
- Three user-definable output ranges (from 0-10 ppm through 0-250,000 ppm) assuring a perfect match for the user’s process and equipment
- Air-calibration range for convenient spanning at 20.9%
- Auto-Ranging automatically selects the proper preset range for a given measurement. Manual override allows the user to lock onto a specific range of interest.
- Two adjustable concentration alarms and a system failure alarm
- Extensive self-diagnostic testing at start-up and on demand with continuous power-supply monitoring
- Two way RS-232 serial digital port for use with a computer or other digital communication device
- Four analog outputs; two for measurement (0-1 VDC and Isolated 4-20 mADC) and two for range identification
- Linearity of analysis across three user-programmable ranges
- AutoRanging capabilities
- Digital interface allows monitoring from a remote station
- Extended-life, maintenance-free sensor
- Comprehensive self testing function
| Ranges |
: 3 customer programmable ranges (minimum 0-10 ppm) with AutoRanging |
| Calibration range |
: 0-25% |
| Response time |
: 90% of FS at 77°F (25°C) in less than 65 seconds |
| Analysis display |
: 5 digit red LED, 3/5” high numerals |
