RTD To DC Current/Voltage Isolator/Converter Z109PT2-1

Z-Line Series offers a full range of signal conditioners including analog/digital/serial converters, temperature transmitters, galvanic isolators, splitters, trip amplifiers and math modules. They work at 10-40 Vdc/ 19-28 Vac, 85-265 Vac/dc or are supplied by the loop. Z-Line modules ensure from 1.500 Vrms to 4.000 Vrms isolation voltage for 1 minute at three points. They also supply the transducer and can have active/passive input/output and they are designed to be mounted on DIN 46277 rail.

Talk to Our Experts Download Datasheet

They work at 10-40 Vdc/ 19-28 Vac, 85-265 Vac/dc or are supplied by the loop.
Z-Line modules ensure from 1.500 Vrms to 4.000 Vrms isolation voltage for 1 minute at three points.
They also supply the transducer and can have active/passive input/output and they are designed to be mounted on DIN 46277 rail.
Z-Line Series offers a full range of signal conditioners including analog/digital/serial converters, temperature transmitters, galvanic isolators, splitters, trip amplifiers and math modules.

SENECA Z-Line offers three setting options.
Almost all of the existing models allows configuration of standard parameters using the dip switches on board.
In addition to the standard configuration some models can be configured for widen functionalities by using the PC software “EASY SETUP“ .
Moreover, certain models are equipped with a frontal Micro Usb port for an easier configuration through “EASY SETUP APP“, a specific App for Android.

Power supply : 19..40 (9..30 opt.) Vdc; 19..28 Vac; (50..60 Hz)
Power consumption : 2.5 W
Power transducers : Yes, active input 2 wire (min 20 Vdc)
Accuracy : ±0,01% /°C
