PolyTrans P 32000
The PolyTrans P 32000 universal transmitters provide connection possibilities for all standard thermocouples, resistance thermometers, strain gauge full bridges, resistors and potentiometers/resistive sensors. They can be flexibly adapted to the respective measuring task using DIP and rotary encoder switches or via an IrDA interface. 3-port isolation with protective separation up to 300 V AC/ DC according to EN 61140 ensures optimum protection of personnel and equipment as well as unaltered transmission of measuring signals. The PolyTrans P 32000 offer maximum performance in the smallest of spaces. Resistance thermometers can be operated in 2-, 3- or 4-wire configuration. The connection configuration is automatically recognized, adjustment is not required. All commercial thermocouples can be detected with internal or external reference junction compensation.
- Automatic detection
- High accuracy
- Reduced inventory
- Low-cost assembly
- Minimum space requirement
- Universal usability
- Convenient parameter setting
- Intuitive configuration
- Calibrated range selection
| Input |
: 200 ohms ... 50 kohms |
| Connection |
: 3- or 4-wire |
| Supply current |
: 0 to 5 mA |
| Weight |
: Approx. 60g |
